Experiments, Prototypes & Notes with the micro:bit v2.21
This repository contains my projects, experiments, and notes using the micro:bit v2.21, built on the nrf52833 microcontroller.
It serves as a playground for testing ideas, learning embedded concepts, and building small prototypes.
🟠 Synchronization is a fundamental concept that ensures that the processor, peripherals, timers, and interrupts operate in a consistent and accurate manner based on a common clock source.
🟠 Clock is the basis for timers and interrupts The clock system sets the pace of all digital components of the microcontroller. Timers use its signals to generate interrupts and perform tasks with precise time control.
🟠 Interrupts allow the microcontroller to instantly respond to important events without wasting resources on constantly polling the peripherals.
When an interrupt occurs, the CPU suspends the current task, goes to the Interrupt Service Routine (ISR), performs the required action, and returns back.
🟠 Timers are hardware modules of the microcontroller for actions with time counting and event generation without the participation of the main code.
The accuracy of the timer and its maximum time range depends on its bit depth, the clock frequency to which it is connected and the value of the divider.
Microcontroller peripherals are functional blocks integrated into the chip that enable it to interact with the outside world or carry out specific tasks — often without involving the processor core.
🟠 When selecting a microcontroller, your choice should depend on the required peripherals, not the other way around.
A processor register is a quickly accessible location available to a computer's processor.
Registers usually consist of a small amount of fast storage, although some registers have specific hardware functions, and may be read-only or write-only.
Its used to store data, operands, calculation results, memory addressing, peripheral control, and microcontroller operation during instruction execution.
Each register has a specific function and bit capacity.
🟠 When performing an arithmetic operation, the processor may load the operands into general-purpose registers, perform the operation, and then store the result in another register or in memory.
🟠 A must-have template for creating a Rust project for microcontrollers.
